Inverter Air Conditioner

Product & Package

Technical Support

Contact

微信掃一掃
關(guān)于銀河微電子公眾號(hào)
了解最新產(chǎn)品與公司新聞

產(chǎn)品分類

?	Line module	Product classification	Product model
? Indoor unit of air conditioner? ?	Primary rectification	Bridge Rectifiers	DB107S ?DB207S ??GBS2M ?TBF20M
	Buffer circuit	Standard Recovery Rectifiers	1N4007 ?1N5399
	Buffer circuit	Fast Recovery Rectifiers	HER106G ?ES1J ?ES3JB ?HER206G ?HER208G
	step-downDC/DC	LDO	PS1117-3.3
	Feedback circuit	Photocouplers	BL817 ?BL817M BL1010H
	Feedback circuit	Adjustable Shunt Voltage Regulators	TL431
	Secondary rectifier 5V output	Schottky Diodes	SB130 ?SB1100
	Secondary rectifier 12V output	Schottky Diodes	SB3100 ?SB3200 ?SB5100 ?SB5200
Outdoor unit of air conditioner	Primary rectification	Bridge Rectifiers	GBU15M ???GBU25M
	???PFC Circuit	Fast Recovery Rectifiers	MUR3060
	PFC bypass protection	Standard Recovery Rectifiers	8A10 ?10A10
	Buffer circuit	Standard Recovery Rectifiers	1N4007 ?1N5399
	Buffer circuit	Fast Recovery Rectifiers	HER106G ?ES1J ?ES3JB ?HER206G ?HER208G
	step-downDC/DC	LDO	PS1117-3.3
	Fan motor drive	Power MOSFETs	BL5N50D BL9N30F BL4N60F
	Primary switch	High voltage MOSFETs	BL6N80F ?BL7N80F ?BL3N90F
	Secondary rectifier 5V output	Schottky Diodes	SB360 SH36B
	Secondary rectifier 12V output	Schottky Diodes	SB3100 ?SB3200 ?SB5100 ?SB5200 ?SS310B SS3200B ?SS510B ?SS5200B
	Secondary rectifier 15V output	Schottky Diodes	SB1200 ?SB2200 ?SS3100B ?SS3200B
